Compliant & Connected: Bridging Rooftop Solar with EVN’s Grid Using MAXiCom

Posted on by Admin

Navigating the New Solar Regulations

The landscape of renewable energy in Vietnam is evolving. With the introduction of Decree 58/NĐ-CP and Decision 429/QĐ-EVN, the government and EVN have established a strict legal framework for developing, connecting, and monitoring rooftop solar power systems.

For investors and operators, compliance is no longer optional. Specifically, Decision 378/QĐ-EVN outlines the technical requirements for connecting self-consumption rooftop solar sources to EVN’s monitoring and control systems .

The Technical Challenge: What EVN Requires

Connecting a rooftop solar system to the national grid involves more than just plugging in cables. For systems with a capacity of 100kW or greater, strict technical criteria must be met:

  • Monitoring & Control: Systems must be capable of exchanging data with the grid operator and receiving control commands .
  • Protocols: Communication must utilize standard protocols like Modbus TCP or IEC 60870-5-104 .
  • Security: Data channels between the solar source and the monitoring system must be encrypted .
  • Connectivity: The connection utilizes 3G/4G/5G or the Internet to link the investor’s system with the Power Company’s SCADA/monitoring center .

Meeting these requirements requires a robust gateway solution. Enter MAXiCom.

The Hardware Solution: MAXiCom Gateway

MAXiCom is a specialized hardware solution designed to bridge the gap between your rooftop solar system and EVN’s management systems.

Key Features

  • Universal Compatibility: It is compatible with the majority of inverters currently on the market.
  • Resilient Operation: MAXiCom operates independently and stores operational data locally, ensuring no data is lost even if the connection to the center is interrupted.
  • Secure Connection: It creates a secure VPN tunnel directly on the device to transmit metering data to the Power Company .

Powerful Specifications

Built for industrial environments, the MAXiCom device features a Quad-core Cortex-A55 processor and 4GB of RAM. It supports diverse communication ports including RS485, CAN, and Gigabit Ethernet, with optional 4G-LTE and Dual-band Wi-Fi. Security is paramount, with support for TLS and OpenVPN/IPSec.

Tailored Packages

MAXiCom offers flexible packages based on system size:

  • RT400: Supports up to 10 Inverters / 400kW .

  • RT700: Supports up to 15 Inverters / 700kW.

  • RT1000: Supports up to 20 Inverters / 1000kW.

All packages include 24/7 monitoring and 1 year of free Cloud service .

The Software Powerhouse: ATDigital IoT

 To visualize and manage the data collected by MAXiCom, AT Energy provides the ATDigital IoT cloud platform. This is a centralized command center for your solar assets.

Comprehensive Monitoring & Control

  • Real-time Tracking: Monitor continuous yield and update the operational status of panels, inverters, and storage systems .
  • Remote Control: The system allows for P (Active Power) and Q (Reactive Power) control settings sent to the MAXiCom device, including scheduling for Zero Export functionality .
  • Fault Management: Instant alerts are generated for abnormalities, supporting proactive maintenance planning.

Advanced Data Analytics

ATDigital IoT features a “Low-code” rule chain engine, allowing users to easily drag and drop logic to process data, create alarms, or forward data to other systems . The platform supports hybrid databases (SQL and NoSQL) to handle massive time-series data efficiently.

Multi-Platform Access

Whether you are in the office or on the go, ATDigital IoT is accessible via Web App, Android App, and iOS App.

Conclusion: Seamless Integration for a Greener Future

By combining the MAXiCom gateway with the ATDigital IoT platform, solar investors can ensure full compliance with Decree 58/NĐ-CP and Decision 378/QĐ-EVN. This integrated solution not only satisfies legal requirements but also optimizes operational efficiency through real-time data analysis and remote control capabilities.

Ready to connect your Rooftop Solar system? Contact AT Energy for a consultation on the MAXiCom solution today.
